John Deere X590 with 122 or 137 cm (48 or 54 in.) Deck


Lawn and Garden

Ride on mowers

X500 Series

  • Accel Deep™ Deck
  • V-twin, air-cooled engine with iTorque™ Power System
  • Constant speed governor technology
  • 4 year/500 hour limited warranty

Machine Features

V-twin engine has electronic fuel injection (EFI) and constant-speed governor for quick starts and superior performance

Smooth-running V-twin engineSmooth-running V-twin engine
Hood with vents for engine airHood with vents for engine air

The tractor is powered by a John Deere iTorque™ power system, a combination of engine features and an exclusive hood design providing superior lugging ability, even cooling, and durability. Key engine features include:

  • 25.5 hp (19 kW) at 3500 rpm
  • Large 726-cc displacement
  • V-twin air-cooled design
    • Excellent power and performance
    • Smooth, quiet power
    • Easy starts
  • Quality features include:
    • Cast-iron cylinder liners
    • Overhead valves
    • Full-pressure lubrication
    • Replaceable oil filter
    • Dual-stage air cleaner
  • Solenoid-shift starter for easy starts, even in cold weather
  • Electronic fuel injection (EFI)

    • EFI meters the correct amount of fuel directly into each engine cylinder for all operating conditions.
    • It simplifies engine starts and warm-up by eliminating the need for the operator to use a choke.
    • Fuel usage is reduced up to 10 percent compared to a carbureted engine.
  • Constant-speed governor

    • Constant-speed governor works in conjunction with EFI to electronically adjust the supply of fuel air mixture, to increase torque as needed to maintain engine operating speed under load.
    • Ground speed and mower blade-tip speed remain constant, even in heavy-grass conditions, to improve productivity and cut quality.
      • Mechanical governors cannot respond fast enough to maintain a constant engine speed.
    • Some torque rise remains to warn the operator before the engine stalls.
    • X590's constant-speed governor is a first in the mowing industry.
Electronic fuel injection and constant-speed governor
X590 Tractor dash, no choke requiredX590 Tractor dash, no choke required
Electrically actuated air inlet valveElectrically actuated air inlet valve

No choke control is needed for the EFI engine because a servo motor controls the intake air butterfly valve and the air stream. For cold starts the actuator will close the valve, making starting the engine easier - no choke lever is needed. Starts are quick and easy - even for inexperienced operators.

The advanced engine features provide the following advantages:

  • Constant-speed governor improves performance.

    • Mowing time is reduced as the constant-speed governor keeps the engine operating at optimum speed, responding instantaneously as the mower transitions from light to heavy mowing.
    • Cut quality is improved, especially in difficult mowing conditions, because the constant-speed governor keeps the mower blades turning at full speed, delivering optimal cut quality and dispersion of clippings.
  • EFI increases uptime.

    • Fast, reliable starts are routine just like with a modern automobile. EFI automatically meters fuel, including the extra fuel needed to start a cold engine. Flooding by unnecessary choking of a warm engine is eliminated. No carburetor adjustments are needed at altitude.
    • No choke-related problems since the choke is eliminated, thus ensuring operator confidence and quick starts, even in cold ambient temperatures. The mechanical throttle cable is replaced by an electric linkage that is not susceptible to wear or freezing.
  • Cost of ownership is reduced.

    • EFI precisely meters fuel to each engine cylinder. Fuel usage can be expected to be about 10 percent less than with a similar carbureted tractor.
    • Reduced maintenance expense because of fewer complaints related to hard starting, vapor lock, misfire, run-on, or fouled spark plugs.
  • The X590 Tractor, including the engine, is covered by a 4-year/500-hour bumper-to-bumper warranty*.

Flywheel alternator

A flywheel alternator provides plenty of capacity to quickly recharge the battery and power electrical equipment, such as lights or a sprayer:

  • 15-amp capacity
  • Regulated to keep the battery at a full charge, without risk of overcharging

*Term limited to years or hours used, whichever comes first, and varies by model. See the LIMITED WARRANTY FOR NEW JOHN DEERE TURF AND UTILITY EQUIPMENT at or for details.

Exact Adjust ports and on-board deck-leveling tools make precise deck adjustments easy

Deck-leveling gauge and hex adjusting tool stored under tractor seatDeck-leveling gauge and hex adjusting tool stored under tractor seat
Exact Adjust access holesExact Adjust access holes

A mower deck must be level side-to-side and properly adjusted front-to-rear to give the best cutting performance. A removable on-board deck-leveling gauge and a hex-key tool are provided to make adjustment easy. They are securely stored under the tractor seat.

Exact Adjust leveling ports are provided on each side of the operator platform above the mower-level adjusting bolts. With the hex-shaped tool, they provide convenient access to allow quick and easy adjustment of the mower for the best-cut quality of cut.

The Exact Adjust feature is standard on all Select Series™ X300 and X500 Tractors:

  • There is no need to reach under the fender deck while making the mower-level adjustment.
  • On-board deck-leveling gauge, Exact Adjust ports, and the hex tool work together.
    • Level the mower deck side to side
    • Set the correct amount of rake (front-to-back deck orientation)
    • Calibrate the cutting height to the cut-height adjusting knob setting
  • Exact Adjust simplifies leveling the mower deck if equipped with a Power-Flow™ blower.
    • To give the best cut, mower level should be adjusted if alternately mowing with and without blower installed. The Exact Adjust feature makes this easy.
Deck-leveling tool placed under deckDeck-leveling tool placed under deck
Using included ball-hex tool to level mower deckUsing included ball-hex tool to level mower deck

Consult the operator's manual for the correct adjusting procedures for each tractor model. Basic adjusting steps to properly level the mower deck include:

  • Park the tractor on a level surface.
  • Inflate tires to the correct pressure.
  • Consult the label for the cutting-height knob that is located on the console of the machine. This label shows deck-leveling position and location of deck-leveling adjustment points.
  • Set mower cutting-height knob to the correct deck-leveling position.
    • For X300 models, use position 2.75
    • For all other models, use position 2.5
  • Adjust mower wheels as necessary so they do not contact the ground surface.
  • Remove the onboard deck-leveling gauge that is located under the seat.
  • Using the Exact Adjust ports and tool, adjust mower deck side-to-side level so the deck-leveling gauge just slips under the left and right lower deck rim at the designated adjustment points. The location of adjustment points will vary slightly between decks.
    • Left- and right-rear adjustment points are under the deck rim near the rear mower wheels, if equipped.
  • Adjust mower deck front-to-back level, if necessary.
    • Loosen rear nuts equally on each side of front lift rod.
    • Turn front nut equally on each side clockwise to raise front of mower or counterclockwise to lower it until gauge just slips under the front adjustment point.
    • Tighten rear nuts after adjustment is complete.
  • Return the gauge to its storage position.

NOTE: The adjusting tool supplied with the tractor is an 8-mm ball-hex key, part number M162737. The rounded end allows for some misalignment with the bolt as the deck is adjusted.

The 54-in. (137-cm) Accel Deep™ (54A) Mower Deck cuts clean and is versatile

X394 with Accel Deep 54A MowerX394 with Accel Deep 54A Mower
Accel Deep 54A MowerAccel Deep 54A Mower

The 54-in. (137-cm) Accel Deep Mower Deck is a stamped-steel, deep, flat-top design that delivers excellent cut quality, productivity, cleanliness, durability, and versatility. Optimal performance and dispersion of clippings is provided, even at faster mowing speeds:

  • 4.83-in. (12.3-cm) depth throughout the entire deck shell for optimum mowing, mulching, and bagging performance
    • Optional MulchControl™ attachment provides superior mulching performance and versatility.
  • Stamped-steel design eliminates sharp edges and corners where material can build up and diminish mowing performance
  • Mower deck is suspended from the vehicle for a smooth and level cut
    • Adjustable mower wheels, positioned just above ground level, help reduce scalping
Excellent cut quality
54A Mower top54A Mower top
54A Mower underside54A Mower underside

Deep mower-deck stamping gives excellent cut quality. It allows the cut and suspended material room to exit the deck without getting recut:

  • Reducing the amount of re-cutting enables more power to be used to cut incoming grass, which greatly improves mower capacity.
    • Helps maintain excellent cut quality at faster mowing speeds
  • Clean flow of material out of discharge area prevents cut material from interfering with cutting the incoming grass, making it possible for the blades to cut incoming material cleanly.
  • Even in mulching mode, cut evenness is improved compared to other designs because the additional depth allows for continuous circulation, optimal re-cutting, and an even distribution of clippings.
Productivity - getting the job done fast
Right side of Accel Deep 54A Mower DeckRight side of Accel Deep 54A Mower Deck

Deep mower-deck stamping gives high productivity, which gets the job done fast. It allows the cut and suspended material room to exit the deck quickly, reducing the amount of re-cutting so more power is available to process incoming grass:

  • Greatly improves mowers capacity to maintain excellent mowing performance in difficult mowing conditions and at higher speeds

Large discharge opening is both high and wide to handle more material:

  • Gives a smooth, even discharge of clippings at all mowing speeds
  • Reduces the chance of plugging, especially important when operating in wet, thick, or dense grass and when bagging
  • The 54A Power Flow™ blower has an inlet housing with over 20 percent greater area than the 54X Power Flow blower used on previous machines.

Cleaning a mower deck, both top and bottom, is one of the most frequent maintenance activities:

  • The flat-top design reduces places for material to build up and makes material that does collect easy to remove.
Mower wash portMower wash port
Mower wash port with hose connectorMower wash port with hose connector

A wash port is provided to make cleaning the underside of the mower deck easy.

  • Hose connector is included with the mower deck.
Versatility - easy to change between side discharge, mulch, and bagging modes

The 54A mower is designed for maximum versatility, providing the greatest ease in changing from one mower discharge mode to another:

  • With the optional MulchControl attachment installed (along with the special mulching blades), changing from side-discharge to mulching or vice versa is done with the simple flip of a lever.
  • The Power Flow rear bagger can be used with the MulchControl attachment and blades installed - by simply placing the MulchControl lever in the side-discharge position.
MulchControl option

The MulchControl attachment for the 48A Mower Deck makes mulching more practical for many mowing situations because it not only does an excellent job of mulching but it also allows the mower to be easily converted for times when it is more desirable to side discharge or collect the lawn material. Advantages of mulching grass clippings include:

  • A beautiful looking lawn
  • Grass clippings not blown onto the operator, driveways, or flower beds
  • Less fertilizer use
  • Elimination of the effort needed to dispose of clippings
How MulchControl works
MulchControl baffle openMulchControl baffle open
MulchControl baffle closedMulchControl baffle closed

MulchControl is an innovative, simple design that is easy to use and maintain:

  • The MulchControl attachment includes baffles to control the flow of material under the deck.
    • The left mower-blade area is completely enclosed and optimized for mulching, thus will mulch even when the mower is in the side-discharge mode.
    • Baffles around the center and right blades are optimized for mulching when the discharge baffle is closed.
Cleanliness - for the mower and the operator
Accel Deep 54A Mower DeckAccel Deep 54A Mower Deck
Accel Deep 54A Mower DeckAccel Deep 54A Mower Deck

The flat-top shape of the deck stamping is optimal for keeping itself and the operator clean:

  • There are few places to catch and hold material on top and underneath the deck.
    • Top of deck stays cleaner, reducing time and effort needed for cleaning and service
    • Underside of deck is self-cleaning to maintain optimum performance without build-up of material to interfere with the flow of air and clippings
    • Less need to clean and remove build-up of material from underside deck
  • The depth of the Accel Deep mower deck minimizes the amount of material that escapes from the front of the deck
    • Limited amount of material to drift onto the operator and mower deck
    • Even for material discharged out the chute, less re-cutting results in larger pieces that are less likely to end up on the operator
    • Mulching prevents the discharge of material completely and the MulchControl attachment makes mulching a practical solution for most mowing situations.
Superior durability is designed in
Spindle pocket with flip-up coverSpindle pocket with flip-up cover
Easy-to-adjust mower wheel and mower side reinforcementEasy-to-adjust mower wheel and mower side reinforcement

The 54A Mower Deck has strong spindle pockets, to keep the blades aligned, even after years of tough service:

  • Ribs in the deck shell add strength where it is needed.
  • The 54A has a 3 percent heavier overall weight than the Edge™ Xtra 54-in. (137-cm) mower deck used on previous machines.

Mower wheels are heavy duty:

  • Provides greater strength and durability for longer, trouble-free life.
  • Setting wheels to the correct height for the cutting height quick and easy.

Low-tension belt-drive design reduces the side load on engine lower bearings and mower deck bearings for longer life.

The 54A Mower Deck features a 5/8-in. (16-mm) diameter solid-steel rod side bumper that provides extra strength and protection.

Dual-stage E-coat and powder-paint coatings provide extra protection from rust.

MulchControl baffle closedMulchControl baffle closed
MulchControl handleMulchControl handle
  • The MulchControl handle is located on top of the mower deck and used to open and close the discharge baffle.
    • The operator is required to get off of the machine in order to engage or disengage mulch mode.
  • Changing from mulching to side discharge or vice versa takes only a few seconds.

MulchControl is well-suited to the following mowing situations:

  • Usually mulch, but side discharge when grass gets too long
  • Usually side-discharge, but would like to be able to close the chute to control clippings
  • Always mulch a main lawn, but often side discharge secondary lawns
  • Bag clippings, but want to go farther before emptying bags

MulchControl puts the operator in control of the clippings. Now the operator can have all the benefits of mulching with the ability to easily change to side discharge or bagging when needed.

6.5-bu (230-L) Power Flow rear bagger
Optional rear baggerOptional rear bagger
Power Flow blowerPower Flow blower

Power Flow blower and chute are easy to install. The Power Flow blower swings out for easy cleanout and cleanup.

While in the side-discharge mode, MulchControl will still mulch about one third of the material. Therefore, the side-discharge mode is essentially a partial-mulch mode. This can be an advantage when side discharging or bagging, as it helps to reduce the amount of material being discharged. Other times this could work as a disadvantage:

  • When cutting strong southern grasses, such as Zoysia and Bermuda
  • When cutting in wet, high-growth conditions, such as those found in the Pacific Northwest United States
  • When optimum bagging and lawn clean-up is desired

Modern styling is eye appealing and functional

Attractive stylingAttractive styling
Side-hood ventsSide-hood vents

Smooth, rounded contours present a modern, styled appearance:

  • Hood styling incorporates efficient full-length air-intake louvers on each side.
    • Cooler engine operation
    • Lower operator station sound levels
  • Hot air is vented out the front grill, away from the operator.
  • Xenoy® molded-in-color hood material is very durable.
    • Excellent impact strength
    • Hides scratches
    • Will not rust or dent
  • Distinctive grille, large footrest area, and one-piece fender deck complete the styling package.

Xenoy is a trademark of SABIC Innovative Plastics.

Power steering gives easy turns

Power steering cylinderPower steering cylinder

Hydraulic power steering is standard equipment:

  • Provides effortless automotive-like control
  • Reduces operator fatigue and increases productivity
  • Offers a tight turning radius for great maneuverability
  • Adjustable-tilt steering wheel for optimum operator comfort (X584 and X590)

Frame is formed from heavy-duty steel and welded for reliability

Heavy-duty welded frameHeavy-duty welded frame
Rear weight bracket/hitchRear weight bracket/hitch

The frame is made of heavy-duty formed steel, reinforced in critical areas and welded for even greater strength:

  • Frame is formed from 12-gauge, 0.105-in. (2.66-mm) thick material.
  • Rear hitch plate is formed from 0.25-in. (6.4-mm) steel and completes the frame assembly.
  • Rear hitch plate can support up to four 42-lb (19-kg) Quik-Tatch weights.
  • Optional front bumper for the X570 Tractor can support up to four 42-lb (19-kg) Quik-Tatch weights.

Request a Quote


Error, ensure all information is entered

Your content has been submitted

Our Branches


Lot 10 York Road, Quairading, WA, 6383

PO Box 71, Quairading, WA, 6383

(08) 9645 0077
Contact Us


2 Great Eastern Highway, Cunderdin WA 6407

2 Great Eastern Highway, Cunderdin WA 6407

(08) 9635 1364
Contact Us


3 Shadbolt Street, Mukinbudin, WA, 6479

3 Shadbolt Street, Mukinbudin, WA, 6479

(08) 9047 1109
Contact Us


20 Yilgarn Avenue, Northam, 6401

PO Box 276, Northam, 6401

(08) 9622 5855
Contact Us


14 Latham Rd, Narembeen, WA, 6369

PO Box 303 Narembeen, WA, 6369

(08) 9064 7214
Contact Us


Lot 1474 East Barrack Street, Merredin WA 6415

PO Box 250, Merredin, WA 6415

(08) 9041 4100
Contact Us

More Info

The information on this page is correct at time of publish and as per John Deere Aus. We reserve the right to change content at any time without prior notice. For more information please contact us.

Last Updated :

December 12,2018 12:21:09 Central Standard Time

Related Products

Ag Implements_Logo_Only.png

X584 with 122 or 137 cm (48 or 54 in.) Deck


The X584 Ride-on Mower with 122 or 137 cm (48 or 54 in.) Deck has four-wheel steering for superior manoeuvrability and tight trimming. Other features include power steering with a ...

Ag Implements_Logo_Only.png

X580 with 137 cm (54 in.) Deck


The John Deere X580 Select Series™ Ride-on Mower offers unmatched quality, performance, comfort, and versatility in a multi-terrain ride-on mower. It has a powerful iTorque™ Power ...

Ag Implements_Logo_Only.png

X570 with 122 cm (48 in.) Deck


The John Deere X570 Select Series™ Ride-on Mower offers unmatched quality, performance, comfort, and versatility in a multi-terrain ride-on mower. It has a powerful iTorque™ Power ...
